1.High sealing to protect the gas environment, double air outlet design;
2. Four-channel pulse excitation and frequency acquisition;
3. Intelligent PID fuzzy temperature control, 7-inch touch screen centralized control, can visually display the "time-temperature" curve;
4. Scientific and reasonable structure, highly compatible with supporting test components, improve test efficiency.

Model

NBD-LM1700-22TIF

Electrical Spec

AC220V  4.5KW

Tmax

1650 ℃

Type B thermocouple

The heating rate can be reached

≤  20 ℃/min

Furnace space

220×260×220mm

Control system

1. Adopt automatic control mode, touch screen real-time display of equipment data;
2. The experiment process is more intuitive and the operation is more convenient;
3. It has the functions of overtemperature alarm, broken couple warning, leakage protection and so on.

Temp Accuracy

+/- 1 ℃

Heating element

Equipment details

gas control

The float flowmeter is used to control the gas flow rate, which is integrated with the equipment, and the leakage test has been carried out before the factory.

Service

1 year warranty with lifetime support (warranty does not include consumable parts)
