Equipment features:
1. Double layer air-cooled structure;
2. High purity Al2O3 fiber refractory insulation material, energy-saving and consumption reducing;
3. The high-purity aluminum oxide coating on the heating element can extend its service life;
4. The NBD-101 intelligent control system allows you to operate worry free and get started in 3 minutes.

Product model

NBD-O1200-25TIY

7"

1.2KW

K-type thermocouple

1200℃

Heating temperature zone

Rated temperature

Long term usage temperature

pipe diameter

Furnace body size

heating rate

weight

≈30KG

Over temperature alarm, overcurrent protection, and disconnection prompt

control system

1. 15 temperature curves can be pre stored to avoid the trouble caused by repeated settings of different experimental processes;
2. The experimental process is more intuitive and the operation is more convenient;
3. NBD-101E embedded operating system with Chinese and English interchangeable graphical interface, 7-inch true color touch screen input, intelligent human-machine dialogue mode, non-linear style temperature correction;

Pressure measurement and monitoring

Temperature accuracy

+/- 1 ℃

Heating element

Mo doped Fe Cr Al alloy
