System composition and core components
1. High temperature lifting furnace unit
·Heating system: Using preferred silicon molybdenum rods and other heating elements, combined with high-purity alumina fiber furnace, it can achieve a stable working temperature of 1700 ℃.
·Temperature Control System: Equipped with a precision programmed temperature controller, it can set and accurately execute up to dozens of stages of temperature rise, hold, drop, and curve, ensuring process repeatability.
·Security guarantee: Integrated multiple security mechanisms such as over temperature protection, power-off protection, and mechanical interlocking.
2. Industrial robot unit
·Mechanical arm: Typically, six axis articulated robots or four axis SCARA robots are used, which have high flexibility, high repeatability positioning accuracy (up to ± 0.1mm or even higher), and a wide range of workspace.
·End effector: Specially customized according to material characteristics such as crucibles, boxes, wafers, etc., we can provide you with fixtures, trays, vacuum suction cups, etc.
·Protective measures: Robot cables and key components can be equipped with high-temperature protective covers to cope with thermal radiation in the furnace area.
3. Automated loading and unloading platform
·It usually includes an incoming material buffer area, a finished product output area, and a positioning station, which are used for the temporary storage and precise positioning of materials, forming a complete logistics cycle.
4. Central Integrated Control System
·Control core: PLC or industrial PC is used as the main controller.
·Human machine interface: equipped with a touch screen, providing an intuitive operation interface that can start and stop with one click, monitor equipment status in real-time, temperature curves, robot action sequences, etc.
·Communication integration: Seamless integration of robot controllers and temperature controllers through industrial buses (such as Profinet, EtherCAT) or Ethernet, achieving full process collaborative linkage.
