Equipment features

1. Use contactless thyristor module to improve the stability of system control;
2. The use of advanced technology of refractory insulation materials, small heat loss, effectively reduce the use of equipment power;
3. High melting efficiency, good energy saving effect, uniform metal composition;
4. With automatic inclined discharge function, can quickly carry out casting molding operations;

Model

NBD-P1500-2.5LTI

NBD-P1700-2.5LTI

Electrical Spec

AC220V 4KW

AC220V 5KW

Tmax

1450℃

1650℃

Heating rate

≤20℃/min

Furnace volume

2.5L

Control system

1. Liquid crystal display centralized control, temperature rise process at a glance;
2. 15 temperature curves can be pre-stored, and 30 sections of "temperature-time" curves can be set for each one to avoid the trouble caused by repeated setting of different experimental processes;
3. It has the functions of over-temperature alarm, broken couple warning, leakage protection and so on.

Dumping mode

Automatic dumping of samples by motor control makes the operation safer and more reliable.

Temp Accuracy

+/- 1℃

Heating element

High purity silicon carbon rod

High purity silicon molybdenum rod

Net weight

75KG

110KG

Cautions

1. When the furnace temperature of the equipment is ≥300℃, do not open the furnace to avoid damage;
2. Slight cracks caused by continuous use of the furnace are normal and do not affect the normal use of the equipment;

Service

1 year warranty, 2 years of touch system warranty, lifetime support (warranty does not include consumable parts)
