1. Adopt high purity quartz or stainless steel furnace tube, excellent corrosion resistance and high temperature resistance;
2. High purity Al2O3 fiber refractory insulation material, excellent insulation effect, reduce the power consumption of equipment;
3. The furnace body adopts double-layer air-cooled structure technology, and the upper cover is opened by automatic lifting system;
4.NBD-101EP embedded operating system Chinese and English interchange graphical interface, 7 inch real color touch screen input, intelligent man-machine dialogue mode, real-time heating power display, non-linear pattern temperature correction; The experimental report is generated independently, and the experimental data is exported for unlimited times.
5. Integrated equipment includes multi-channel air supply system, multi-temperature zone heating system and high vacuum system.

Number of heating-zone

3

4

5

6

Tube size

Ø25/Ø50/Ø60/Ø80/Ø100*1600mm

Max working temps.

≤1150℃

Heating zone selection

(Customizable)

200mm*3

200+300+200mm

200+400+200mm

300mm*3

300+400+300mm

200mm*4

200+300+300+200mm

200+400+400+200mm

300mm*4

300+400+400+300mm

200mm*5

300mm*5

200mm*6

300mm*6

Heating rate

≤20℃/min

Electrical Specifications

AC380V 6~10KW

AC380V 8~14KW

AC380V 10~15KW

AC380V 12~18KW

Gas system (optional)

Piping diagram

Number of intake ports

2、3、4(Multiple options available)

Traffic range

20-250/20-800ml/min......(Multiple ranges available)

50/100/200/500sccm......(Multiple ranges available)

Working pressure range

0-0.15MPa

Low vacuum system (optional)

Vacuum pump model

NBD-3C/NBD-4C

Pumping speed

3L/s或4L/s

Inlet and outlet port size

KF16/25

System vacuum

3~5Pa(Vacuum pump ultimate vacuum 6.2*10^-2 Pa)

Working environment temperature

5-40℃

Electrical specifications

AC220V

High vacuum system (optional)

Vacuum pump model

NBD-103(A)

NBD-103(B)

Pumping speed

110L/s

600L/s

Vacuum gauge

Compound vacuum gauge

System vacuum

4.310^-3Pa

6*10^-4Pa

Working temperature

5-40℃

Electrical specifications

AC 220V

AC 380V

*Support non-standard customization. For more models, please call 400-000-3746 for inquiries
