Equipment features:

1, can achieve vacuum or atmosphere sintering;
2, can achieve rapid sample cooling;
3, the sample can be automatically lifted and dropped;
4, ring heating, sample heating more uniform.

Control system

1, sintering process curve setting: dynamic display setting curve, equipment sintering can prestore multiple process curves, each process curve can be set freely;
2, can be reserved sintering, to achieve unattended sintering process curve sintering;
3, real-time display of sintering power and voltage information and record sintering data, and can be exported to achieve paperless recording;
4, with remote control, real-time observation of equipment status;
5, temperature correction: the difference between the main control temperature and the sample temperature, the whole sintering process for nonlinear correction.

heating furnace

  2 sets of heating furnaces (divided into left and right chambers, can be heated separately or simultaneously)

Chamber size

Φ150*200mm

Pressure measurement & monitoring

Mechanical pressure gauge with damping oil prevents gauge pointer from being damaged (digital vacuum gauge is optional)

vacuum system

Vacuum degree: ≤5Pa (mechanical pump)

measuring range

RT—1100℃

Heating rate

30℃/min,  Recommended heating rate ≤ 10℃/min

cooling system

Crucible material

310S

Sample measuring environment

Air environment; Static, dynamic atmosphere environment; Or vacuum environment (≦1000℃)

operational process

First, vacuum is pumped, gas displacement is carried out through the atmosphere, and then the sample is sent from the transition bin to the glove box chamber, the sample is fixed on the electric lifting motor, sent into the crucible for processing, and then lifted into the glove box for rapid cooling by air cooling.

Cautions

1. The internal pressure of the gas supply cylinder is high, and when the gas is passed into the glove box, the pressure reducing valve must be installed on the cylinder. It is recommended to choose a small pressure reducing valve for testing, and the measuring range of the pressure reducing valve is 0.01 MPA-0.15 MPa, which will be more accurate and safe in use.

2.310S stainless steel pot long-term use temperature ≦1100℃;

3. When vacuuming, the cover plate of the glove flange should be sealed with the vacuum chamber, and then open the valve on the flange pipe, and then start vacuuming, otherwise the glove will be blown when directly vacuuming;

4. During the heating experiment, always pay attention to the indicator of the pressure gauge. If the absolute pressure gauge reading is greater than 0.15MPa, the exhaust valve must be opened immediately to prevent accidents.

standard configuration

1. One single-station glove box;
2. Vacuum system 1 set;
3. 2 sets of electric lifting system;
4. 1 set of water cooling system
5. A copy of the manual.

Service

1 year warranty, lifetime service (warranty does not include consumable parts).

Net weight

400KG
